Introduction

FWEIDE525D-1 is ideally suited for tailgate interface applications for removable-media drives - CD-ROM, CD-R, CD-RW, DVD-ROM, DVD-RAM, tape drive, and hard disk drive. It allows IDE drives to be connected to a 1394 serial bus in a plug-and-play fashion. Both ATA and ATAPI devices are supported using the same firmware.

Technical Specifications

FireWire interfaces available Transfer speeds up to 100/200/400 Mbps Plug and Play/Host Swapping capability No jumper pins or ID settings Provide two 5.25" device bay Support most types of IDE storage devices Two FireWire (IEEE 1394a) 6pin Connector in the rear panel Built-in 80W power supply/Universal auto-switching 90-240V AC Built-in 80x80 mm cooling fan

Applications

CD Copier DVD & CD Backup Data Storage

Hardware Requirements

Desktop PC: with either a built-in Firewire (IEEE 1394) port or a Firewire (IEEE 1394) to PCI Host Adapter. Notebook PC: with either a built-in Firewire (IEEE 1394) port or a Firewire (IEEE 1394) to CardBus PC Card.

Operating System Requirements

Windows 98 SE/ME/2000/XP/Vista/7 ; MacOS 9.1 or higher Apple FireWire driver set 2.3 or higher

Kit includes

FWEIDE525D-1 enclosure AC Power Core (2.0m length) FireWire 6pin-to-6pin cable (1.0m length) Installation guide 1-YEAR WARRANTY
